HAGEN XL
Room for hauling massive stuff | Can fit 4 small children | Can fit an adult with ease
Technical specifications
NON ELECTRIC HAGEN XL
| Brakes | Shimano MT-200 with 180mm rotors |
| Brand | Hagen Bikes |
| Cargo bed | 100 x 55 cm. |
| Gears | A) Shimano Deore 10 speed B) Shimano Alfine internal 8 speed C) Shimano Nexus internal 5 speed |
| Dropouts | Horizontal with disc mount and derailleur hanger. Compatible with internal and external gears. |
| Frame color | Yellow, Black, White, Custom |
| Frame size | One size fits all – 53cm. |
| Front wheel size | 20" |
| Material | Aerospace grade 4130 Chromoly (Round tubing), Steel (Box sections) |
| Max load | 180 kg (cargo + rider) |
| Rear wheel size | 700c |
| Seatpost diameter | 27,2 mm |
| Tires | 55-622, 55-406 |
| Weight | 28,5 kg |
ELECTRIC HAGEN XL
| Brakes | Shimano MT-200 with 180mm rotors |
| Brand | Hagen Bikes |
| Gears | A) Shimano Deore 10 speed B) Shimano Alfine internal 8 speed C) Shimano Nexus internal 5 speed |
| Dropouts | Horizontal with disc mount and derailleur hanger. Compatible with internal and external gears. |
| Frame color | Yellow, Black, White, Custom |
| Frame size | One size fits all – 53cm. |
| Front wheel size | 20" |
| Material | Aerospace grade 4130 Chromoly (Round tubing), Steel (Box sections) |
| Max Load | 180 kg (cargo + rider) |
| Rear wheel size | 700c |
| Seatpost diameter | 27,2 mm |
| Tire Color | Black |
| Tires | 55-622, 55-406 |
| Motor | Brose S Mag 90 Nm, 250W |
| Battery | 17,5 Ah |
| Lights | Headlight - Litemove SE-110, 110 lux / 550 lumens, Rearlight - Litemove TS-FD, 7200mcd |
| Cargo Bed | 100 x 55 cm |
| Weight | 41,3 kg |
