Hagen XL

2290.00

Tax included. Shipping calculated at checkout.
Description

Mini Cargo Bike is a short version of the standard bike. If you need a compact bike for confined spaces that can still haul a heavy load – that’s the one! You can choose the external geared Altus 9-speed on or ultra-maintenance-free belt-driven Alfine 8-speed opinion.

Key Features

  • Great turning circle
  • Most responsive handling
  • Compact to park

Technical Specifications:

BrakesShimano MT-200 with 180mm rotors
BrandHagen Bikes
Cargo bedsize is 44,5×44,5cm.
GearsA) Shimano Deore 10 speed B) Shimano Alfine internal 8 speed C) Shimano Nexus internal 5 speed
DropoutsHorizontal with disc mount and derailleur hanger. Compatible with internal and external gears.
Frame colorYellow, Black, White, Custom
Frame sizeOne size fits all- 53cm.
Front wheel size20"
MaterialAerospace grade 4130 Chromoly (Round tubing), Steel (Box sections)
Max load180 kg (cargo + rider)
Rear wheel size700c
Seatpost diameter27,2 mm
Tires55-622, 55-406
Weight26,1 kg

Configuration costs: -

HAGEN XL

Room for hauling massive stuff | Can fit 4 small children | Can fit an adult with ease

Technical specifications

NON ELECTRIC HAGEN XL

BrakesShimano MT-200 with 180mm rotors
BrandHagen Bikes
Cargo bed100 x 55 cm.
GearsA) Shimano Deore 10 speed B) Shimano Alfine internal 8 speed C) Shimano Nexus internal 5 speed
DropoutsHorizontal with disc mount and derailleur hanger. Compatible with internal and external gears.
Frame colorYellow, Black, White, Custom
Frame sizeOne size fits all – 53cm.
Front wheel size20"
MaterialAerospace grade 4130 Chromoly (Round tubing), Steel (Box sections)
Max load180 kg (cargo + rider)
Rear wheel size700c
Seatpost diameter27,2 mm
Tires55-622, 55-406
Weight28,5 kg

ELECTRIC HAGEN XL

Brakes Shimano MT-200 with 180mm rotors
Brand Hagen Bikes
Gears A) Shimano Deore 10 speed B) Shimano Alfine internal 8 speed C) Shimano Nexus internal 5 speed
Dropouts Horizontal with disc mount and derailleur hanger. Compatible with internal and external gears.
Frame color Yellow, Black, White, Custom
Frame size One size fits all – 53cm.
Front wheel size 20"
Material Aerospace grade 4130 Chromoly (Round tubing), Steel (Box sections)
Max Load 180 kg (cargo + rider)
Rear wheel size 700c
Seatpost diameter 27,2 mm
Tire Color Black
Tires 55-622, 55-406
Motor Brose S Mag 90 Nm, 250W
Battery 17,5 Ah
Lights Headlight - Litemove SE-110, 110 lux / 550 lumens, Rearlight - Litemove TS-FD, 7200mcd
Cargo Bed 100 x 55 cm
Weight 41,3 kg
Frame Color

Standard Yellow, Custom

Gears

External Deore 10 (E09), Internal 8 Alfine (I08), Internal Belt 8 Alfine (B08)
